NICHIA NUMM34 Multiple Laser diode Array | Projector RGB Laser Light Source
Original price was: $507.00.$497.00Current price is: $497.00. & Free Shipping
- NICHIA NUMM34 multiple laser diode package with 28-chip RGB array. High heat dissipation and pulse operation.
- Ships fast | Safety packing | 30 days returns | 180 days warranty
- Welcome bulk order.
NICHIA NUMM34 Multiple Laser Diode Projector Light Source
The NICHIA NUMM34 is a high-power R,G,B laser matrix. 7-series x 4 connection 28 collimated beams, Special for laser projector and laser tv.
Specifications
| Product Name | Nichia Multiple Laser diode matrix |
|---|---|
| Model | NUMM34 |
| Beams | 28 collimated beams |
| Configuration | R, G, B multiple laser diode |
| Drive Current | |
| Storage Temperature | −40 °C to 85 °C |
| Operating Temperature | 0 °C to 55°C |
| Optical Output Power | B: 29W, G: 11.5W, R: 25W |
| Wavelength | B: 465nm, G: 525nm, R: 639nm,643nm,647nm |
| Voltage | B: 28.5V, G:32.5V, R: 29.5V |
| Lifespan | > 20,000 hours |
| Origin | Japan |
Applications
- Laser projectors & Hession laser TVs
- Laser positioning systems
- Stage & event lighting
- Laser engraving & marking
- Automotive fog lamps
- Laser landmarks & beam shows
- High-power flashlights
- Fingerprint forensic analysis
- Medical & beauty devices
Optional Driver Circuit
We provide a custom-designed driver for the NUMM34 laser diode.
Click here to purchase the compatible driver.
Why Choose NICHIA NUMM34?
Engineered by NICHIA for exceptional optical stability, NUMM34 ensures reliable performance under demanding conditions. Its robust packaging and precision optics make it suitable for both Laser Projector and TV.
Shipping & Warranty
- 🚚 Ships within 24–72 hours
- 🌍 Global tracked delivery (est. 14 business days)
- 📦 Shockproof protective packaging
- 🔄 30-Day worry-free returns
- 🛡️ 365-day warranty included
