USHIO HPL Compact Filament Halogen Lamp – 230V – for Stage, Studio & Medical Therapy Devices
Please select your wattage and life variant from the dropdown menu. This listing is for one genuine USHIO HPL compact filament halogen lamp. These high-performance 230V lamps are the original OEM light source for professional entertainment lighting fixtures (such as ETC Source Four) and medical therapy devices including the Hydrosun 750 wIRA system. USHIO’s redesigned HPL+ ultra-compact filament delivers up to 20% more optical efficiency compared to standard HPL lamps.
Bare bulb only – no housing or fixture included. These lamps feature a G9.5 medium bi-pin base with an integrated ceramic heat sink. Installation must be performed by a qualified technician. Always handle halogen lamps with care and avoid touching the quartz envelope with bare fingers.
Note for medical therapy users: The 750W XN variant (1500-hour long-life) is the correct replacement lamp for the Hydrosun® 750 wIRA water-filtered infrared-A therapy system and similar medical irradiation devices that specify HPL750WXN/230V. This lamp directly replaces the original equipment bulb in Hydrosun 750, Lifowave-WIRA 750, and compatible infrared treatment units.
Five Variants – Choose Your Wattage & Rated Life
All variants share the same G9.5 base with heat sink, T6 bulb shape, and compact filament design. Select the variant that matches your fixture’s power rating and required lamp life.
| Variant | Wattage | Voltage | Color Temp | Lumens | Rated Life | Primary Application |
|---|---|---|---|---|---|---|
| HPL230V-750WXN | 750W | 230V | 3050K | 15,600 lm | 1,500 hours | Long-life: Medical therapy (Hydrosun 750, wIRA), stage/studio, ETC Source Four |
| HPL230V-575WXN | 575W | 230V | 3050K | 11,780 lm | 1,500 hours | Long-life: Stage/studio, ETC Source Four, Hydrosun 575home |
| HPL230V-375WXN | 375W | 230V | 3000K | 7,250 lm | 1,000 hours | Standard-life: Stage/studio, ETC Source Four |
| HPL230V-750WCN | 750W | 230V | 3200K | 19,750 lm | 300 hours | High-output: Stage/studio, theater, ETC Source Four |
| HPL230V-575WCN | 575W | 230V | 3200K | 14,900 lm | 400 hours | High-output: Stage/studio, theater, ETC Source Four |
Compatible Equipment
These USHIO HPL lamps fit all fixtures and devices designed for the HPL 230V lamp platform with G9.5 base and integrated heat sink.
| Application | Compatible Equipment |
|---|---|
| Medical Therapy | Hydrosun® 750 wIRA irradiator, Hydrosun® 750 T, Hydrosun® 575home, Lifowave-WIRA 750 (Pro/Exp), and other water-filtered infrared-A (wIRA) therapy devices specifying HPL750WXN/230V or HPL575/230X+ |
| Stage & Studio | ETC Source Four, Source Four JR, Source Four PAR, and all ellipsoidal / PAR fixtures using HPL 230V lamps with G9.5 heat sink base |
Compatibility Notes: The Hydrosun 750 medical device uses the HPL750WXN/230V long-life variant (1,500 hours). The Hydrosun 575home uses the HPL 575W XN variant. Always verify your original lamp’s wattage, voltage, and base type before ordering. If your device or fixture is not listed above, contact us with your equipment model and original lamp specifications—we will confirm the correct variant at no charge.
Genuine USHIO – 100% Original, Never Re-Lamped
This is a brand-new, original USHIO HPL halogen lamp—not a used bulb that has been re-lamped or refurbished. Every lamp we sell is manufactured by USHIO in Japan as a complete, sealed unit. No recycled parts, no re-lamped cores. Using a genuine OEM lamp ensures reliable ignition, stable color temperature, and full rated lamp life. Generic compatible bulbs often suffer from filament sag, color temperature drift, and premature failure.
365-Day Replacement Warranty
All HPL lamp variants are covered by a full 365-day warranty against manufacturing defects.
Fast, Tracked Shipping
Ships promptly with tracking. Packed securely to prevent damage during transit.
Select your preferred wattage and life variant from the dropdown above. Restore your stage fixture or medical therapy device to full brightness with a genuine USHIO HPL lamp.
