NICHIA NUBB23 Laser Diode Bank Overview
The Nichia NUBB23 Laser Diode Bank is a high-power blue laser diode module delivering 22W output at 455nm. It features a 4x LD chip array (4-series connection) with collimated beams for precise optical performance, such as high-intensity laser projection, engraving, stage lighting, and scientific applications.
NUBB23 Specifications
| Product Name and Model | Nichia NUBB23 Blue Laser Bank |
|---|---|
| Configuration | 4 LD chips, 4-series connection |
| Drive Current | < 3.5 A |
| Storage Temperature | -40°C to 85°C |
| Operating Temperature | 0°C to 70°C |
| Optical Output Power | 22W |
| Wavelength | 455nm |
| Voltage | 14V to 18V |
| Lifespan | > 20,000 hours |
| Origin | Japan |
Applications
The NICHIA NUBB23 is ideal for:
- Laser projectors & laser TVs
- Laser positioning systems
- Stage & event lighting
- Laser engraving & marking
- Automotive fog lamps
- Laser landmarks & beam shows
- High-power flashlights
- Fingerprint forensic analysis
- Medical & beauty devices
Compatible driver: A custom-designed driver for the NUBB23 is available. Click here for driver details.
