NICHIA NUBM33 Laser Module – High‑Power Blue Diode Array (71W, 455nm)
The NICHIA NUBM33 is a high‑power blue laser diode array designed for demanding optical applications such as laser projection, industrial systems, and scientific research. Featuring 15 collimator beams in a 5 series x 3 parallel configuration, it delivers 71W output power at 455nm with excellent beam quality and thermal performance. The compact module includes a mounting bracket for easy integration.
Technical Specifications – NUBM33 Laser Diode Array
| Product Name | Nichia Blue Laser Module |
|---|---|
| Model | NUBM33 |
| Output Power | 71W |
| Wavelength | 455 nm |
| Voltage | 55–67V |
| Current | < 3.5 A |
| Lifespan | > 20,000 hrs |
| Operating Temperature | 0°C – 75°C |
| Storage Temperature | -40°C – 85°C |
| Origin | Japan |
Key Features – NUBM33 Blue Laser Diode Array
- 15 Collimator Beams – Integrated blue laser diodes for high‑density output
- 5 Series x 3 Parallel Connection – Optimized electrical configuration
- Compact Diode Array Module – Includes mounting bracket for easy integration
- High Heat Dissipation – Designed for efficient thermal management
- Easy Driver Compatibility – Works with compatible constant‑current laser drivers
- Long Operational Life – >20,000 hours under proper conditions
Applications for NUBM33 Laser Module
- Laser projection systems (cinema, large venue, home theater)
- Laser engraving and cutting machines
- Scientific research and laboratory use
- Industrial and medical laser equipment
- Laser lighting and stage effects
- Large‑scale laser landmark installations
Important Handling & Installation Notes
This laser module is static‑sensitive and requires proper ESD protection during handling. Ensure adequate heat sinking and thermal management to maintain junction temperature within specifications. Do not exceed maximum drive current or operating temperature. Always use a compatible constant‑current laser driver with appropriate current limiting.
Optional Driver Circuit for NUBM33
We provide a custom‑designed driver specifically for the NUBM33 laser diode array.
Click here to purchase the compatible driver (please verify compatibility before ordering).
Shipping & Warranty
- ✅ Ships within 24–72 hours
- ✅ Global tracked delivery (est. 14 business days)
- ✅ Shockproof ESD‑safe packaging
- ✅ 30‑day worry‑free returns
- ✅ 365‑day warranty included (manufacturing defects)
Why Choose the NICHIA NUBM33 for Your Laser Project?
NICHIA is a world leader in laser diode technology, and the NUBM33 delivers proven 71W blue light output at 455nm in a compact, easy‑to‑integrate package. With its 15‑beam collimated array (5S3P configuration), robust thermal design, and long lifespan, this module is ideal for demanding projection, engraving, and research applications. Backed by a 365‑day warranty and responsive technical support, you can integrate with confidence.
✅ Order the NUBM33 blue laser module today and unlock high‑power blue laser performance!
